Greenlee Feeding Sheave 2-1/2″ Conduit 441-2-1/2

• Greenlee
• Feeding Sheave for 2 Conduit 441-2
• Yoke frame slides into the end of conduit and holds sheave; allowing the cable being fed into the conduit to smoothly roll over the sheave
• 5.000 IN (127.000 MM) wide aluminum alloy sheave with self-Lubricating bearings
• Split tube for easy removal after cable is installed
• Capacity : 1900.000 LB (8.400 KN) At 15 DEG; 1000.000 LB (4.400 KN) At30 DEG; 700.000 LB (3.100 KN)At 45 DEG; 550.000 LB (2.400 KN) At 60 DEG; 500.000 LB (2.200 KN) At 75 DEG; 500.000 LB (2.200 KN) At 90 DEG
• Includes : 25160 UPC 25160 Sheave Pin; 50302 UPC 50302 Sheave Pin Clip(2); 15362 UPC 15362 Sheave
• Weight : 11.000 LB (5.000 KG)

“
